Hycat™ OA-4

Colorless Epoxy Anhydride Catalyst

Hycat™ OA-4 is a proprietary low viscosity liquid catalyst that accelerates the reaction of a broad range of epoxy resins with a wide variety of anhydride curing agents. Hycat™ AO-4 is a clear and colorless product used to promote the reaction of epoxy/anhydride formulations that require exceptional clarity and light transmission characteristics in the final cure. Hycat™ AO-4 is a latent catalyst that provides very long pot life and produces moderate to high glass transition temperatures (Tg).

Anhydride reactions catalyzed by Hycat™ AO-4 include Hexahydrophthalic Anhydride (HHPA), Methylhexahydropthalic Anhydride (MHHPA), Methyltetrahydrophthalic Anhydride (MTHPA), Nadic Methyl Anhydride (NMA), Maleic Anhydride (MA), Phthalic Anhydride (PA) and more. Typical epoxides include Bisphenol A Diglycidyl Ether (BADGE), Bisphenol F Diglycidyl Ether (BFDGE), Cycloaliphatic Diepoxide, NOVOLAC, Tetrafunctional Methylene Dianiline and more.

DSC Profile of MHHPA / BADGE

Typical kinetic profile of an epoxy/anhydride reaction catalyzed by Hycat™ AO-4. Click on the PDF links at the bottom of this page for the complete view of this and other reaction profiles.

DSC Profile of MTHPA / Cycloaliphatic

Typical kinetic profile of an epoxy/anhydride reaction catalyzed by Hycat™ AO-4. Click on the PDF links at the bottom of this page for the complete view of this and other reaction profiles.

Commercial Applications:

Coatings
Filament Winding
Potting & Encapsulation
Reinforced Plastics
Resin Infusion
Sheet Moulding Composites
Wet & Spray Layup
And More….

Industries:

Aerospace
Automotive & Transportation
Clean Energy (Windmill Fabrication)
Coatings
Construction
Electronics
Sports & Leisure
And More…

Hycat™ 3100S Physical Properties

Form…………................…...
Color……………................…
Viscosity (cP)……...............
Density………...............……
Shelf Life…..............…….…

Liquid
Emerald Green
< 100 cP
1.0g/mL @ 25oC
5 Years

Available Quantities

200L Drums…………..…….
50L Drums……………..……
20L Pails…………………..….
Evaluation Samples…..…

200 Kgs (441 Lbs)
50 Kgs (110 Lbs)
20 Kgs (44 Lbs)
60g (2 oz)
